1/8" Pressure-field Microphone, Externally Polarized
Pressure-field microphone designed for very high-frequency measurements in confined spaces with a frequency range of 6.5 Hz to 140 kHz.Angebot anfordern
Type 4138 is designed for high-level and very high-frequency measurements and measurements in confined spaces. Being externally polarized, Type 4138 must be used with a classical preamplifier.
- High-level and very high-frequency measurements
- Applications which require a high degree of spatial resolution or where space is limited, for example, model testing
USE OF PRESSURE-FIELD MICROPHONES
Pressure-field microphones should be used for making measurements in small, closed couplers or close to hard, reflective surfaces. Such microphones are optimised to have a flat frequency response in a pressure field. Because of its small size, Type 4138 can also be used for random-incidence measurements at audio frequencies, where its frequency response is less dependent on angle of incidence.
Type 4138 requires an external polarization voltage and therefore must be used with a classical preamplifier such as Brüel & Kjær Type 2670 together with 1/8-inch to 1/4-inch Adaptor UA-0160.
The sensitivity of Type 4138 can be calibrated at 250 Hz using Pistonphone Type 4228, or at 1 kHz using Sound Calibrator Type 4231, in both cases using Adaptor DP-0774.
The pressure-field response can be measured using Electrostatic Actuator UA-0033 with Actuator Adaptor DB-0900.
- 3.5 pF
- Dyn. range
- 43 – 168 dB
- Freq. range
- 6.5 – 140000 Hz
- Inherent noise
- 43 dB A
- Lower limiting frequency -3dB
- 0.05-5 Hz
- Ext polarized
- Polarization voltages
- 200 V
- Pressure coefficient
- -0.01 dB/kPa
- 1 mV/Pa
- Temperature coefficient
- -0.01 dB/ºC
- Temperature range
- -30 – 100 ℃
- Sound field
- Input type
- Microphone type
- Pressure Field
