The UA-2116-120 allows up to 12 charge type transducers to be connected directly to the LAN-Xi front end, simplifying the setup and the performance.
- Charge type transducers: Accelerometers, pressure sensors, hydrophones
- Combustion pressure monitoring on up to 12-cylinder engines
- High channel count charge accelerometer applications
Ideal for high channel-count charge accelerometer applications and in power train applications. It is ideal for combustion pressure monitoring on up to 12-cylinder engines.
The charge input front has 12 integrated charge amplifiers each with a fixed gain of 0dB (-1mV/pC) and a fixed High-Pass Filter of 0.1Hz. Setting up the fronts in PULSE works in the same way as using an external -2647.
Built-in LEDs shows input status such as overload. It has 12 x 10-32UNF(F) microdot connectors.
|Compatible LAN-XI module
